要画“2025 中超联赛各队排名折线图”，我需要每轮排名的数据。你有每轮的球队名与排名吗？如果有，给我一个 CSV 或数据源链接，我直接帮你生成图。没有数据也行，我可以写脚本，等你把 CSV 放进去就能出图。
下面给一份通用脚本，读取每轮排名并输出折线图（名次从上到下 1→N），支持筛选球队或只画最终前 N 名。
使用说明
- CSV格式要求（列名不区分大小写，中文也可）:
- 轮次: round / 轮次 / r
- 球队: team / 球队 / club
- 名次: rank / 名次 / position
- 安装: pip install pandas matplotlib
- 执行:
- 画全部球队: python plot_csl_rankings.py --input standings_2025.csv
- 只画前 6 名: python plot_csl_rankings.py --input standings_2025.csv --top 6
- 指定球队: python plot_csl_rankings.py --input standings_2025.csv --teams 上海海港,山东泰山
- 指定输出: --output csl_2025.png
代码（保存为 plot_csl_rankings.py）
#!/usr/bin/env python3
import argparse
import sys
from pathlib import Path
import pandas as pd
import matplotlib.pyplot as plt
from matplotlib import cycler
# Try to show Chinese labels if fonts available
plt.rcParams["font.sans-serif"] = ["SimHei", "Noto Sans CJK SC", "Microsoft YaHei", "Arial"]
plt.rcParams["axes.unicode_minus"] = False
plt.style.use("seaborn-v0_8-whitegrid")
def normalize_columns(df: pd.DataFrame) -> pd.DataFrame:
mapping = {}
for c in df.columns:
lc = str(c).strip().lower()
if lc in ["round", "轮次", "r", "round_no", "matchday"]:
mapping[c] = "round"
elif lc in ["team", "球队", "club", "俱乐部"]:
mapping[c] = "team"
elif lc in ["rank", "名次", "position", "pos"]:
mapping[c] = "rank"
elif lc in ["season", "赛季", "year"]:
mapping[c] = "season"
else:
mapping[c] = lc # keep as-is for potential future use
df = df.rename(columns=mapping)
required = {"round", "team", "rank"}
if not required.issubset(df.columns):
missing = required - set(df.columns)
raise ValueError(f"Missing required columns: {missing}. "
f"Have columns: {list(df.columns)}")
return df
def pick_teams(df: pd.DataFrame, teams_arg: str | None, top: int | None) -> list[str]:
all_teams = sorted(df["team"].unique())
if teams_arg:
wanted = [t.strip() for t in teams_arg.split(",") if t.strip()]
# keep order as provided, validate existence
missing = [t for t in wanted if t not in all_teams]
if missing:
raise ValueError(f"Teams not found in data: {missing}. Available: {all_teams}")
return wanted
if top:
# determine final round, then pick top N by the final round rank
last_round = int(df["round"].max())
last_table = df[df["round"] == last_round].sort_values("rank")
return last_table["team"].head(top).tolist()
return all_teams
def main():
ap = argparse.ArgumentParser(description="Plot CSL 2025 ranking trajectory by round.")
ap.add_argument("--input", required=True, help="CSV with columns: round, team, rank")
ap.add_argument("--output", default="csl_rankings_2025.png", help="Output image path (png/svg)")
ap.add_argument("--teams", default=None, help="Comma-separated team names to include")
ap.add_argument("--top", type=int, default=None, help="Only plot top N teams (by final round)")
ap.add_argument("--title", default="2025中超联赛排名走势", help="Chart title")
ap.add_argument("--width", type=float, default=12.0, help="Figure width inches")
ap.add_argument("--height", type=float, default=7.0, help="Figure height inches")
args = ap.parse_args()
csv_path = Path(args.input)
if not csv_path.exists():
print(f"Input not found: {csv_path}", file=sys.stderr)
sys.exit(1)
df = pd.read_csv(csv_path)
df = normalize_columns(df)
# Coerce types
df["round"] = pd.to_numeric(df["round"], errors="coerce")
df["rank"] = pd.to_numeric(df["rank"], errors="coerce")
df = df.dropna(subset=["round", "team", "rank"])
df["round"] = df["round"].astype(int)
df["rank"] = df["rank"].astype(int)
# Sort and basic sanity
df = df.sort_values(["round", "rank", "team"])
rounds = sorted(df["round"].unique())
if len(rounds) == 0:
raise SystemExit("No rounds found in data.")
max_round = rounds[-1]
max_rank = int(df["rank"].max())
teams = pick_teams(df, args.teams, args.top)
# Pivot to have rounds as index, teams as columns
pivot = df.pivot_table(index="round", columns="team", values="rank", aggfunc="min")
# Ensure all rounds exist as index
idx = pd.Index(range(int(min(rounds)), int(max_round) + 1), name="round")
pivot = pivot.reindex(idx)
# Figure
fig, ax = plt.subplots(figsize=(args.width, args.height))
# Color cycle
colors = plt.cm.tab20.colors + plt.cm.tab20b.colors + plt.cm.tab20c.colors
ax.set_prop_cycle(cycler(color=colors))
# Plot each selected team
plotted = []
for team in teams:
if team not in pivot.columns:
continue
y = pivot[team]
# If there are missing ranks for some rounds, leave gaps
ax.plot(pivot.index, y, marker="o", linewidth=2, markersize=3, label=team)
plotted.append(team)
if not plotted:
raise SystemExit("No selected teams were found in the data to plot.")
# Rank axis: 1 at top
ax.invert_yaxis()
ax.set_ylim(max_rank + 0.5, 0.5)
ax.set_yticks(range(1, max_rank + 1))
ax.set_xticks(pivot.index)
ax.set_xlabel("轮次")
ax.set_ylabel("排名")
ax.set_title(args.title)
# Move team labels to the right of last round
x_right = max_round + 0.5
for line, team in zip(ax.get_lines(), plotted):
y_last = line.get_ydata()[-1]
if pd.isna(y_last):
# find last valid
valid = pd.Series(line.get_ydata()).dropna()
if not valid.empty:
y_last = valid.iloc[-1]
else:
continue
ax.text(x_right, y_last, team, va="center", fontsize=9)
# Expand x limit to make space for labels
ax.set_xlim(pivot.index.min() - 0.2, max_round + 2.0)
# Tidy
ax.grid(True, axis="both", linestyle="--", alpha=0.3)
for spine in ["top", "right"]:
ax.spines[spine].set_visible(False)
# Legend optional (can be crowded). Comment out if using right-side labels.
# ax.legend(ncol=2, fontsize=8)
fig.tight_layout()
out_path = Path(args.output)
fig.savefig(out_path, dpi=200)
print(f"Saved: {out_path.resolve()}")
if __name__ == "__main__":
main()
如果你把一个示例 CSV（含每轮排名）发给我，我可以直接跑脚本并把成品图发给你。或者如果你没有数据，我可以尝试自动抓取 2025 赛季每轮积分榜并生成图，要不要我来抓取并出图？
